Shanghai Raylaser's laser cutting machine systems will boost your
output and ensure high quality and increased productivity.
The laser cutting machine features high precision, high speed,
narrow gap, small heated zone, high flexibility, low maintenance cost,etc.
Mainly Applications: hand railing, bikes, windows, metal
fabrication, electronics manufacturing, the automotive industry,
and aerospace.
1) Configuration and Specification
Machine Configuration
| No | Key parts | Brands |
| 1 | System | Bochu Cypcut |
| 2 | Laser source | Raycus, Max, IPG |
| 3 | Laser cutting head | Raytools Boci Ospri WSX |
| 4 | Chiller | Hanli/S&A |
| 5 | Servo Motor (1300w+850w+400w) | Yaskawa Inovance |
| 6 | Reducer | MOTOVARIO |
| 7 | Rack and Pinion | LEADER/YYC |
| 8 | Rail guideway | HIWIN |
| 9 | Standard electrical parts | Schneider/Shanghai Electric |
| 10 | Electrical proportional valve | O2(<10bar) |
Technical Specification
| No. | Key Performance | Specification |
| 1 | Working area | 6000mm (L) ×230mm (Dia.) |
| 2 | X axis length | 400mm |
| 3 | Y axes length | 6010mm |
| 4 | Z axis length | 300mm |
| 5 | Positioning accuracy | ≤0.03mm |
| 6 | Repeat positioning accuracy | ≤0.02mm |
| 7 | Max.accumulated speed | 100m/min |
| 8 | Max.Acceleration | 1.2G |
| 9 | Load Bearing Capacity | 1500KG |
| 10 | Overall weight | 2500Kg |
| 11 | Machine overall dimensions | L12800mm*W1500mm*H1860mm |
| 12 | Power supply | AC380V/50Hz/≤50KVA |
| 13 | Rating | IP54 |
2) The Crucial Details
The design of a machine is pivotal to its performance
And We build pride by our craftsmanship.
3) 24/7/365 Online Ongoing Expert Support Services
Providing excellent customer service is the surest way to greater
success!
1) The high standard of Installation, commission and training
2) The tips and tricks for High Machine Utilization
3) Follow up the Maintenance Planning & Checkpoints
4) Favorites of Original quality spare parts supply
5) Useful TPM and OEE consultations for free
